Parallel connection of SINAMICS S120 Motor Modules Booksize
The components needed for connecting Motor Modules Booksize in parallel belong to the
SINAMICS S120 series.
Note
SINAMICS Equipment Manuals
The parallel connection of Motor Modules Booksize falls under the scope of the SINAMICS
S120 Equipment Manuals.
● You will find exhaustive descriptions of the devices and their interconnections in these
SINAMICS S120 Equipment Manuals:
– Booksize power units (https://support.industry.siemens.com/cs/ww/en/view/
109766188)
– Control Units and supplementary system components (https://
support.industry.siemens.com/cs/ww/en/view/109763286)
Parallel connection of SINAMICS S120 Active Line Modules Booksize
Descriptions of the
parallel connection of Active Line Modules Booksize with an infeed power
up to 228 kW can be found in this SINAMICS S120 application description:
● Parallel connection of Active Line Modules (
https://
support.industry.siemens.com/cs/ww/en/view/109759667)
Hardware
4.2 Design
Motor Modules Booksize parallel connection
Application Manual, 01/2020, 6SL3097-5BF00-0BP0 29
