Siemens SINUMERIK 802S Technical Manual

Technical Appendix
SINUMERIK 802S base line
6-13
Start-Up
35430 SPIND_OSCILL_START_DIR
- Starting direction during reciprocation
0-2: As last direction of rotation (zero-speed M3)
3: M3 direction
4: M4 direction
RESET
_always 0 0 4 BYTE 2/7
35440 SPIND_OSCILL_TIME_CW
s Reciprocation time for M3 direction NEW CONF
_always 1.0 0.0 plus DOUBLE 2/7
35450 SPIND_OSCILL_TIME_CCW
s Reciprocation time for M4 direction NEW CONF
_always 0.5 0.0 plus DOUBLE 2/7
35500 SPIND_ON_SPEED_AT_IPO_START
- Feed enable for spindle in setp. Range RESET
_always 1 0 2 BYTE 2/2
35510 SPIND_STOPPED_AT_IPO_START
– Feedrate enable for spindle stopped RESET
_always 0 *** ***
BOOLEAN
2/7
36000 STOP_LIMIT_COARSE
mm,
deg.
Exact positioning coarse NEW CONF
_always 0.04 0.0 plus DOUBLE 2/7
36010 STOP_LIMIT_FINE
mm,
deg.
Exact positioning fine NEW CONF
_always 0.01 0.0 plus DOUBLE 2/7
36020 POSITIONING_TIME
s Delay exact positioning fine NEW CONF
_always 1.0 0.0 plus DOUBLE 2/7
36030 STANDSTILL_POS_TOL
mm,
deg.
Zero–speed tolerance NEW CONF
_always 0.2 0.0 plus DOUBLE 2/7
36040 STANDSTILL_DELAY_TIME
s Delay zero–speed monitoring NEW CONF
_always 0.4 0.0 plus DOUBLE 2/7
36050 CLAMP_POS_TOL
mm,
deg.
Clamping tolerance NEW CONF
_always 0.5 0.0 plus DOUBLE 2/7
