Siemens SINUMERIK 802S Technical Manual

Technical Appendix
6-38 SINUMERIK 802S base line
Start-Up
6.2.9 User alarm
Alarm activation
1600 Alarm activation [r/w]
Data block Interface PLC -----> MMC
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Activation of alarm no.
16000000
700007 700006 700005 700004 700003 700002 700001 700000
Activation of alarm no.
16000001
700015 700014 700013 700012 700011 700010 700009 700008
Activation of alarm no.
16000002
700023 700022 700021 700020 700019 700018 700017 700016
Activation of alarm no.
16000003
700031 700030 700029 700028 700027 700026 700025 700024
Variable for alarm
1600
Data block
Variable for alarm [r/w]
Interface PLC -----> MMC
Byte
16001000 Variable for alarm 700000
16001004
Variable for alarm 700001
16001008
Variable for alarm 700002
...
16001116
Variable for alarm 700029
16001120
Variable for alarm 700030
16001124 Variable for alarm 700031
