Technical Appendix
SINUMERIK 802S base line
6-47
Start-Up
Parameter Description
MD14512[11]
Bit 0 = 1 PLC subroutine COOLING will be executed
Bit 1 = 1 PLC subroutine LUBRICAT will be executed
Bit 2 = 1 PLC subroutine LOCK_UNL will be executed
Bit 3 = 1 PLC subroutine SPINDLE will be executed
Bit 6 = 1 PLC subroutine GEAR_CHG will be executed
Bit 7 = 1 PLC subroutine TURRET1 will be executed
MD14512[12]
Bit 0=1 Feed and Spindle override controled by switchs
Bit 0=0 Feed and Spindle override controled by trigger user keys.
Bit 2=1 Record the feed override value of the last machine turn off
for the next startup.
Bit 2=0 Startup feed override is always 100%
Bit 3=1 Record the spindle override value of the last machine turn
off for the next startup.
Bit 3=0 Startup spindle override is always 100%
Bit 4/5 Define feed override shift speed
Bit5 Bit4 Feed override shift speed
0 0 Standard speed. The steps are:
0%,1%,2%,4%,6%,8%,10%,20%,30%,40%,50%,60
%,70%,75%,80%,85%,90%,95%,100%,105%,110%,
115%,120%.
0 1 Two times fast than standard. The steps are:
0%,2%,6%,10%,30%,50%,70%,80%,90%,100%,110
%,120%.
1 0 About three times fast than standard. The steps are:
0%,4%,10%,40%,70%,85%,100%,110%,120%.
1 1 About four times fast than standard. The steps are:
0%,2%,10%,50%,80%,100%,120%.
Bit 6/7 Define spindle override shift speed
Bit7 Bit6 Spindle override shift speed
0 0 Standard speed. The steps are:
50%,55%,60%,65%,70%,75%,80%,85%,90%,95%,1
00%,105%,110%,115%,120%.
0 1 Two times fast than standard. The steps are:
50%,60%,70%,80%,90%,100%,110%,120%.
1 0 About three times fast than standard. The steps are:
50%,60%,70%,85%,100%,110%,120%.
1 1 About four times fast than standard. The steps are:
50%,60%,80%,100%,120%.
