Technical Appendix

SINUMERIK 802S base line

6-49

Start-Up

Definition of MD 14510

MD14510 USER_DATA_INT

Machine data PLC Machine Data – Integer

Index WORD (16 bits Integer)

14510[12] Definition: Time setpoint for feed/spindle override. Press and hold on feed/spindle decrease

key more than the setpoint , the override shifts to 0% and 50% directly

Unit: 100ms

Range: 5 ~ 30(0.5 ~ 3 seconds), if overrun, the default is 1.5s

14510[13] Definition: Time setpoint for feed/spindle override. Press and hold on feed/spindle 100% key

more than the setpoint , the override shifts to 100% directly

Unit: 100ms

Range: 5 ~ 30(0.5 ~ 3 seconds), if overrun, the default is 1.5s

Definition: Machine tool type

14510[16] Unit: -

Range: 0 - Turning machine; 1 - Milling machine; >2 not defined

Definition: Drive type

14510[17] Unit: -

Range: 0 – stepper drive; 1 – analog drive (SimoDrive 611); >2- not defined;

Definition: number of positions on the turret

14510[20] Unit: -

Range: 4, 6, 8 (note: for SAMPLE only 4 / 6 permitted)

Definition: monitor time (turret change abort if destination tool not found within specified time)

14510[21] Unit: 0.1 second

Range: 30 ~ 200 (3 ~ 20 second)

Definition: Turret clamping time

14510[22] Unit: 0.1 second

Range: 5 ~ 30 (0.5 ~ 3 second)

Definition: Braking time of external brake mechanism of a contactor controlled spindle

14510[23] Unit: 0.1 second

Range: 5 ~ 200 (0.5 ~ 20 second)

Definition: Interval of track lubrication

14510[24] Unit: 1 Minute

Range: 5 ~ 300 Minutes

Definition: Duration of lubrication

14510[25] Unit: 0.1 second

Range: 10 ~ 200 (1 ~ 20 second)

Definition: X axis + traverse key position

14510[26] Unit: -
