Installing the Control System
SINUMERIK 802S base line
2-19
Start-Up
T
able 2–17 Electrical parameters of the digital outputs
Parameter
V
alue
Unit
Note
“1” signal, nominal voltage
V
oltage drop
24
max. 3
V
V
“1” signal, output current
0.5
A
Simultaneity
factor
0.5 per 16 outputs
“0” signal, leakage current
max. 2
mA
30
32
Table of Contents
Default Chapter
7
Table of Contents
7
1 SINUMERIK 802S Base Line Control System
9
Components of the SINUMERIK 802S Base Line
9
Technical Data
11
2 Installing the Control System
13
Installing and Dismantling the SINUMERIK 802S Base Line
13
Interfaces and Cables
16
Connecting the Individual Components
19
Connecting the Feed Drives and the Spindle (X7)
19
Configuration of the RS232 Interface Connection (X2)
23
Connecting Handwheels (X10)
25
Connecting BERO and NC-READY (X20)
26
Connecting the Digital Inputs (X100 ... X105)
28
Connecting the Digital Outputs (X200 ,X201)
30
Power Supply for CNC (X1)
32
Leds and Other Elements on CNC
33
3 Installing the STEPDRIVE
35
Installing and Dismantling the STEPDRIVE C/C+ Drive Modules
35
Cabling
37
Starting up the Drive Modules
39
4 Start-Up
41
General
41
Access Levels
42
Structure of Machine Data (MD) and Setting Data (SD)
43
Handling of Machine Data
44
Data Saving
44
Turning on and Booting the Control System
46
Boot Messages
48
Starting up the PLC
49
Commissioning of the PLC
49
Start-Up Modes of the PLC
51
PLC Alarms
52
Machine Control Panel Area Layout
57
PLC Programming
58
Instruction Set
61
Program Organization
67
Data Organization
68
Interface to the Control System
68
Testing and Monitoring the User Program
68
PLC Applications "Download/Upload/Copy/Compare
69
User Interface
71
Technology Setting
71
Commissioning
72
Entering the General Machine Data
72
Starting up the Axes
74
Starting up the Spindle
84
Completing the Start-Up
89
Cycle Start-Up
90
Series Machine Start-Up
91
SINUMERIK 802S Base Line I
91
5 Software Update
93
Updating the System Software Using a PC
93
Update Errors
94
6 Technical Appendix
95
List of Machine and Setting Data
95
Display Machine Data
96
General Machine Data
98
Channel-Specific Machine Data
99
Axis-Specific Machine Data
100
Setting Data
110
PLC User Interface Signals
111
Address Ranges
111
Retentive Data Area
112
CNC Signals
113
Channel Signals
115
Axis/Spindle Signals
122
Signals From/To MMC
127
Machine Control Panel Signals (MCP Signals)
129
PLC Machine Data
130
User Alarm
132
PLC User Program for Turning (SAMPLE)
134
Function
134
Input/Output Configuration
137
Definition of User Keys
138
PLC Machine Data
140
SAMPLE Program Structure
144
User Alarm
146
Start-Up of SAMPLE Program
147
Unipolar Spindle
149
