Start-Up
4-10
SINUMERIK 802S base line
Start-Up
Approach
z
Set MD20700 to zero.
z
Use the Diagnosis/StartUp switch/PLC softkey to select Simulation.
You can check the current setting via Diagnosis/Service display/Version/
PLC application.
z
Select the desired key and check your setting by pressing the key.
Supported keys
z
Mode selection
z
Axis keys
z
NC keys
Notice
The Increment key is only active in the JOG mode. The toggle function can be
used to set increments in the range between 1,10,100 or 1000. Check the
response by pressing the axis direction keys.
Reference Point is not supported.
Standard user program
The control system comes with an universal program, the customer can
choose the technology mode (Turning or Milling) with PLC user machine data.
