Turning and milling functions
PLC sample subroutines for turning functions:
For turning only
SBR 51
Turret1_HED_T
HED turret control
SBR 52
Turret2_BIN_T
Bi-direction turret (binary coded)
SBR 53
Turret3_CODE_T
Bi-direction turret (coded by turret supplier)
SBR 55
Tail_stock_T
Tailstock control
SBR 56
Lock_unlock_T
Chuck control
PLC sample subroutines for milling functions:
For milling only
SBR 60
Disk_MGZ_M
Disk magazine control (without automatic tool changer)
6.6.2
Conventions for the symbols used in the subroutines
The symbols used in the subroutines follow the conventions listed below:
● Leading characters designate the destinations of interface signals.
– P_: to PLC interface
– H_: to HMI interface
– N_: to NCK interface
– M_: to MCP interface
● Subsequent characters are for areas.
– N_: NCK
– C_: Channel
– 1_: Axes
– M_: MCP
● Other short forms of the symbols are as follows.
– HWL:
H
ardware
L
imit
– HW:
H
and
w
heel
– RT:
R
apid
T
raverse
– TK:
T
raverse
k
ey
– ACT:
Act
ive
– SEL:
Sel
ected
● Symbols consist of a maximum of 11 upper case characters and numbers (including the leading character). Except for
underlines, you cannot use any other special symbols like =, +, -, [ ], etc.
