Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
450 01/2017
Asynchronous subroutines (ASUPs): Result
DB3400
ASUP: Result [r]
NCK → PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
1000
INT1
ASUP exe-
cution not
possible
Interrupt
no. not
allocated
ASUP is
being exe-
cuted
ASUP end-
ed
1001
INT2
ASUP exe-
cution not
possible
Interrupt
no. not
allocated
ASUP is
being exe-
cuted
ASUP end-
ed
1002
1003
G functions from NCK channel
DB3500
G functions from NCK channel [r]
NCK → PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Active G function of group 1 (8 bit int)
1
Active G function of group 2 (8 bit int)
2
Active G function of group 3 (8 bit int)
...
...
62
Active G function of group 63 (8 bit int)
63
Active G function of group 64 (8 bit int)
17.10
Axis/spindle signals
17.10.1
Transferred M and S functions, axis specific
DB3700 … 3703
M, S functions [r]
NCK -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
M function for spindle (DINT)
4
S function for spindle (REAL)
17.10.2
Signals to axis/spindle
Common signals to axis/spindle
DB3800 ...
3803
Signals to axis/spindle [r/w]
PLC -> NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Feedrate override
H
G
F
E
D
C
B
A
1 Override
active
Position
measuring
system 2
Position
measuring
system 1
Follow up
mode
Axis spindle
disable
2
Reference point value
Clamping in
progress
Distance-
to-
go/spindle
reset
Drive ena-
ble
4 3 2 1
