Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
418 01/2017
16.2.1
V70 parameters on BOP
The table below lists the parameters displayed on the drive BOP only.
Par. No.
Name
Min
Max
Factory
setting
Unit
Data type
Effective
Can be
changed
r0020
Speed setpoint smoothed
-
-
-
rpm
Float
-
-
Description:
Displays the currently smoothed speed setpoint at the input of the speed controller or U/f
characteristic (after the interpolator).
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
r0021
Actual speed smoothed
-
-
-
rpm
Float
-
-
Description:
Displays the smoothed actual value of the motor speed.
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
r0026
DC link voltage smoothed
-
-
-
V
Float
-
-
Description:
Displays the smoothed actual value of the DC link voltage.
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
r0027 Absolute actual current
smoothed
- - - Arms Float - -
Description:
Displays the smoothed absolute actual current value.
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
Dependency: r0068
r0029 Current actual value field-
generating smoothed
- - - Arms Float - -
Description:
Displays the smoothed field-generating actual current.
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
r0030 Current actual value torque-
generating smoothed
- - - Arms Float - -
Description:
Displays the smoothed torque-generating actual current.
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
r0031
Actual torque smoothed
-
-
-
Nm
Float
-
-
Description:
Displays the smoothed torque actual value.
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
r0032 Active power actual value
smoothed
- - - kW Float - -
Description:
Displays the smoothed actual value of the active power.
Significance for the drive: Power output at the motor shaft
r0033
Torque utilization smoothed
-
-
-
%
Float
-
-
Description:
Displays the smoothed torque utilization as a percentage.
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
r0037[0...19]
Servo drive temperatures
-
-
-
°C
Float
-
-
