Commissioning Manual
202 01/2017
Example for calling subroutine 62
Subroutine 62 for milling application
Set the following PLC machine data for different MCP variants:
Vertical MCP with a reserved slot for
1 Spindle override controlled by trigger user keys
Horizontal/vertical MCP with two
0 Spindle override and feedrate override controlled by
Local variable definition
Inputs
noder WORD Reserved
Increase key of spindle override
DecS_Key BOOL Decrease key of spindle override
Spindle override 100% key
