Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
01/2017
325
Tag identifier
Meaning
FORM
This tag contains the description of a user dialog.
Attributes:
•
color
Background color of the dialog box (for color coding, see Section "Color coding
(Page 323)")
•
name
Identifier of the form
•
type
cycle -attribute specifies a cycle form
•
xpos
X-position of the top left corner of the dialog box (optional)
•
ypos
Y position of the top left corner (optional)
•
width
Extension in the X direction (in pixels) (optional)
•
height
Extension in the Y direction (in pixels) (optional)
•
truetypefont
Whether the font of the dialog form is of the true type (optional)
FORM
continued
Dialog messages:
•
INIT
•
PAINT
•
TIMER
•
CLOSE
•
FOCUS_IN
•
INDEX_CHANGED
•
EDIT_CHANGED
•
KEY_EVENT
•
MESSAGE
