Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
01/2017
377
Function name
Description
control.loaditem
The function inserts a list of expressions into the control.
The function is only available for the control types "listbox" and
"graphicbox".
Syntax:
<function name="control.loaditem"> control name,
list </function>
Attribute:
name
– function name
Values:
control name
– control name
list
- string variable
Structure of the list:
The list contains a number of expressions, which must be separated
from one another using a \n.
Example:
<let name="item_string" type="string"></let>
<let name="plotlist" type="string"></let>
…
…
<print name ="item_string" text="p; %f; %f; %f;
%f\n">s_z, s_x</print>
<op>plotlist = plotlist + item_string</op>
<print name ="item_string" text="l; %f; %f;
%f; %f\n">s_z, s_x, e_z, e_x </print>
<op>plotlist = plotlist + item_string</op>
<op> s_x = e_x </op>
<op> s_z = e_z</op>
<op> e_x = s_x + 10 </op>
<op> e_z = s_z - 100 </op>
<print name ="item_string" text="l; %f; %f;
%f; %f\n">s_z, s_x, e_z, e_x </print>
<op>plotlist = plotlist + item_string</op>
<function name="control.loaditem">_T"gbox",
plotlist</function>
