Programming principles
1.1 Fundamentals of programming
Turning Part 2: Programming (Siemens instructions)
Programming and Operating Manual, 05/2012, 6FC5398-5DP10-0BA0
23
Address Significance Value assignments Information Programming
$A..._..._
TIME
Timer for runtime:
$AN_SETUP_TIM
E
$AN_POWERON_
TIME
$AC_OPERATING
_TIME
$AC_CYCLE_TIM
E
$AC_CUTTING_TI
ME
0.0 ... 10+300
min (value read-only)
min (value read-only)
s
s
s
System variable:
Time since the control system
has last booted
Time since the control system
has last booted normally
Total runtime of all NC programs
Runtime of the NC program
(only of the selected program)
Tool action time
N10 IF
$AC_CYCLE_TIME==50.
5 ....
$AC_..._
PARTS
Workpiece
counter:
$AC_TOTAL_PAR
TS
$AC_REQUIRED
_PARTS
$AC_ACTUAL_PA
RTS
$AC_SPECIAL_PA
RTS
0 ... 999 999 999,
integer
System variable:
Total actual count
Set number of workpiece
Current actual count
Count of workpieces - specified
by the user
N10 IF
$AC_ACTUAL_PARTS==
15 ....
$AC_
MSNUM
Number of active
spindles
read-only
$P_
MSNUM
Number of
programmed
spindles
read-only
$P_NUM_
SPINDLES
Number of
configured
spindles
read-only
$AA_S[n] Actual speed of
spindle n
Spindle number n =1
read-only
$P_S[n] Last programmed
speed of spindle n
Spindle number n =1
read-only
$AC_
SDIR[n]
Current direction of
rotation of spindle
n
Spindle number n =1
read-only
$P_
SDIR[n]
Last programmed
direction of rotation
of
spindle n
Spindle number n =1
read-only
$P_
TOOLNO
Number of the
active tool T
- read-only N10 IF
$P_TOOLNO==12
GOTOF ....
$P_TOOL Active D number of
the active tool
- read-only N10 IF $P_TOOL==1
GOTOF ....
MSG () Signal max. 65 characters Message text in inverted
commas
MSG("MESSAGE TEXT")
; separate block
...
N150 MSG() ; Clear
previous message
