1.2.1 SINUMERIK 810T with integrated machine control panel
SINUMERIK 810T with integrated machine control panel incorporates in a single unit:
• Display panel
• Key panel
• 9” graphics CRT display with integrated function keys (softkeys)
• Integrated machine control panel, with 20 fixed-function operating elements.
SINUMERIK 810T with integrated machine control panel
Integrated
machine con-
trol panel, with
20 fixed-function
operating ele-
ments
Graphics CRT
display with 5 inte-
grated function
keys (softkeys)
SIEMENS SINUMERIK
a a a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a
a a a
•••••
C
D
A
B
Display panel
A
B Key panel
1-2 © Siemens AG 1990 All Rights Reserved 6ZB5 410-0EP02
