09.91 3 Operating Sequences
3.2.12 ”Repositioning” mode (”REPOS”)
3.2.12 ”Repositioning” mode (”REPOS”)
After a program interruption - e.g. after switching from ”AUTOMATIC operation” to ”JOG” or
”Incremental” (INC...) - you can traverse away from the contour.
”AUTOMATIC” operation is not aborted, i.e. the control is not brought to the reset state by a
self-generated ”RESET”:
As described in Section 2.3.4, no ”RESET” is generated by switching from ”AUTOMATIC”
mode to:
– “JOG” or
– “INC ...” or
– “REPOS”.
