Siemens Sinumerik 810T - Extending Menus with the ETC Key

09.91 2 Operation
2.3.5 Branching to operating functions within an operating mode
2.3.5.2 Example for the selection of further operating functions within
the same menu
The menu on the CRT can display max. 5 functions.
(( 810T))
(( Bild 13 von Druckerei
einmontieren
Basic CRT display in
”AUTOMATIC” mode.
First menu of 5 functions.
Basic CRT display in
”AUTOMATIC” mode.
Menu extension with 5
functions.
Operate the ETC key on
the right, below the CRT.
To call further operating functions in the control in the same menu,
you use the ETC key:
Example:
(( 810T))
(( Bild 3 von Druckerei
einmontieren
2.3.5.3 Menu display from the NC program or from the PLC
The control allows you to display any menu from the system or user area at any time. This is
done either via a new interface (DB 40) in the PLC program or a new softkey function (SK 56).
The machine tool manufacturer defines which menus can be displayed when.
For further details see the relevant User's Guide of the machine tool manufacturer.
