11.90 3 Operating Sequences
3.1.15 Data input/data output
Start the output of the R parameters by operating the
”START” softkey.
In the same way, you can select and start the output of data for the following:
”TOOL OFFSET”
”ZERO OFFSET”
”MACHINE DATA”
”PLC MACHINE DATA”
which have not been detailed here.
Using this softkey, you can stop data output at any time...
and continue it again with ”START”.
With the ”ETX-START” softkey you can output the end-
of-transmission character stored in the setting data.
The output is always made irrespective of whether RTS
line or Xon/Xoff protocol have been set.
