09.91 3 Operating Sequences
3.2.9 ”HANDWHEEL”
Select the ”HANDWHEEL” softkey function.
Extend the displayed softkey menu using the ETC
key.
HANDWHEEL
This display appears on the screen.
(( 810T))
(( Bild 53 von Druckerei
einmontieren
The screen display shows you the axis-handwheel assignment which you have set via the axial
setting data (see Section 3.1.6).
Enable of the handwheels connected:
Enter the axis name (e.g. “X”) and press the
“ENABLE” softkey. The “ENABLE” display changes
from “NO” to “YES”. Now handwheel No. 1 applies
to axis “X”. Proceed in an analogous manner for the
other axes (see also Section 3.2.10 “DRF”).
ENABLE
If one handwheel is assigned to several axes by the axis setting data, the enable always appli-
es to the last axis to have been input. On the display, the enable for the other axes automa-
tically changes to “NO”, i.e. the axis is blocked for the handwheel.
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EP02 3-125
SINUMERIK 810T, GA3 (BN)
