09.91 3 Operating Sequences
3.2.12 ”Repositioning” mode (”REPOS”)
Using the direction keys, you traverse to the point of
interruption.
Note:
A maximum of 2 axes can be traversed at one time.
The feedrate override switch is active, the rapid
override key is not active.
+Q+X
+Z– Z
– X– Q
Note :
The direction keys perform in two different ways:
• ”Modal”
•”Jog operation”
When ”Modal” (regardless of whether the key is pressed for a short or a long time), the axis
is always traversed by one increment, in accordance with the setting (1, 10, 100, 1000, 10 000
µm).
In ”Jog operation” the axis is traversed for as long as the key remains pressed. When the
key is no longer being pressed, the traverse movement is stopped - even when the set
increment has not been reached.
