Siemens Sinumerik 810T User Manual

09.91 4 Monitoring Functions
4.6 Listing of the alarms/alarm description
Alarm No.
Alarm Text:
2046
”Block greater than 120 characters”
Reason:
Effect:
Remedy:
There is an incorrect ”LF” in the memory, so that a block containing
more than 120 characters exists.
Inhibiting of NC START
Either insert ”LF”, or delete the complete block
Alarm No.
Alarm Text:
2047
”Option not available”
Reason:
Effect:
Remedy:
A function was programmed that is not included in the function set of
the control.
Inhibiting of NC START
Correct program
Alarm No.
Alarm Text:
2048
”Circle endpoint error”
Reason:
Effect:
Remedy:
The programmed circle endpoint does not lie on the circle.
The tolerance band set in machine data is exceeded.
Inhibiting of NC START
Correct program
Alarm No.
Alarm Text:
2056
”Travel through transf. center”
Explanation:
Remedy:
– On the programmed contour, the radius axis (linear axis) wants to
traverse into the zero of the fictitious coordinate system.
– Change cutter radius.
– Program a different contour.
Alarm No.
Alarm Text:
2057
”Opt. thread/rev. not avail.”
Reason:
Remedy:
Explanation:
– A thread has been programmed in the program with G33, G34, G35
although this function is not available in the control
– Feed per rev. G95 has been programmed.
Correct program.
Alarm with SINUMERIK 810M only.
Alarm No.
Alarm Text:
2058
”3D option not avail.”
Reason:
Remedy:
Explanation:
In the program, 3 axes were programmed simultaneously
Correct program
Alarm with SINUMERIK 810M only
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EP02 4-17
SINUMERIK 810T, GA3 (BN)
