4 Monitoring Functions 01.93
4.6 Listing of the alarms/alarm description
Alarm No.
Alarm Text:
2194
”G36 position rotary axis missing”
Reason:
Remedy:
The alarm only appears with modulo programming. The alarm is
triggered when a G68 is to be generated for the rotary axis in a G36
block:
1. when the rotary axis is programmed for the first time after
RESET or after a C axis switchover using an M function,
2. when the rotary axis is programmed for the first time as
from the target block of a block search with calculation.
For 1. First program the C axis once with G0 or G01
(e.g. G0 G91 C = 0 LF).
For 2. Choose a target block with no G36 and where the C axis is
programmed until the G36 block (additional axes in target
block is also sufficient).
Alarm No.
Alarm Text:
225*
”Spindle speed to high”
Scan:
Explanation:
Remedy:
Only when NC MD 520* bit 2 (encoder available) is set.
The actual spindle speed is higher than set in machine data or setting
data.
• Program lower S value
• NC MD 403* to 410* (max. spindle speed for 1st to 8th gear ratio)
• NC MD 445* (tolerance band of maximum spindle speed)
• NC MD 451* (max. spindle speed)
• Check gear stage via PLC
• Check G92 S... at ”v constant”
• Check setting data for spindle speed limitation
• Program G26 S...
Alarm No.
Alarm Text:
226*
”Control loop spindle hardware”
Scan:
Effect:
Explanation:
Remedy:
Cyclic
• NC START disabled
• Set value relay drops, set value 0
• Mode group ready 2 signal cancelled
• Servo enable of the spindle is removed after the time set in
MD447* has elapsed
• As for Alarm 132*
• As for Alarm 132*
Alarm No.
Alarm Text:
227*
”Measuring system dirty (spindle)”
Scan:
Effect:
Explanation:
Remedy:
Cyclic
NC START disabled
A measuring system with a contamination signal signals a fault to the
NC.
Check the measuring system
4-24
© Siemens AG 1990 All Rights Reserved 6ZB5 410-0EP02
SINUMERIK 810T, GA3 (BN)
