6 Measuring Cycles for Turning and Milling Work 07.90
6.1 L981 Searching for a hole/slot
The following parameters must be defined prior to call:
Parameters Description
R1 Setpoint diameter hole/slot
R2 Reference plane
R10 = 0
= 1-4
= 5
No automatic ZO input
Automatic ZO input in G54 - G57
Automatic ZO input in G58
R18 Centre point linear axis (in radius for transverse axis)
R22 Probe number
R23 = 1
= 2
On face
At cylinder
R25
R25 = 0
Variable measuring speed
Standard cycle velocity
R26 Search increment in degrees (positive only)
R27 = 1...R
max
Number of measurements at same location
R32 Approach setpoint
R36 Safe area (positional tolerance)
6–2 © Siemens AG 1990 All Rights Reserved 6FC5197- AB70
SINUMERIK 840/850/880 (BN)
