3 Measuring Cycle Auxiliary Programs 07.90
3.2.7 L966 Auxiliary program for operator guidance macro (OGM)
3.2.7 L966 Auxiliary program for operator guidance macro (OGM)
This function depends on the
machine configuration.
(See machine tool manufacturer's specifications)
When editing parts of the measuring program via the input displays for measuring cycles, cycle
L966 is cancelled when storing.
3.2.8 L967 Presetting of transfer parameters (internal)
This cycle is normally provided by
the machine tool manufacturer.
(See machine tool manufacturer's specifications)
3.2.9 L969 Auxiliary cycle for coordinate rotation (internal)
This cycle must be available in either the part program memory or in the UMS, if measurement
is to be carried out with coordinate rotation.
This function can be set via MDC.
(See machine tool manufacturer's specifications)
3.2.10 L970 Prepositioning cycle (external)
This cycle offers the possibility of positioning the tools around the tool probe or the workpiece
probe from measuring point to measuring point with active collision monitoring.
The following parameters must be defined prior to call:
Parameters Description
R23 = 0
= 1
Tool measurement (G53)
Workpiece measurement
R25 = ...
= 0
Positioning speed
Rapid traverse/reduced rapid traverse (MDC4 / MDC5)
R30 Axis number of plane
R32 Approach position
referred to machine zero point (R23=0)
referred to workpiece zero point (R23=1) if axis is transverse axis in the
diameter enter value as diameter value
3–6 © Siemens AG 1990 All Rights Reserved 6FC5197- AB70
