3 Measuring Cycles Auxiliary Programs 01.93
3.1 Internal measuring cycle auxiliary programs
3.1 Internal measuring cycle auxiliary programs
The ”internal” auxiliary programs are called directly by the measuring cycles. They can
therefore not be run when called directly by the user.
3.1.1 L931 Auxiliary cycle for tool or workpiece measuring cycles
This cycle must be available in either the part program memory or in the UMS, because it is
used by all measuring cycles.
3.1.2 L932 Check MDC and transfer parameters
*)
This cycle is not absolutely necessary for measurement.
It may be therefore that the program is not available in
the memory.
(See machine tool manufacturer's specifications)
This cycle checks the MDC or the transfer parameters. It is called by the measuring cycles
automatically, if SDC 800 bit 0 or 800 bit 1 is set.
3.1.3 L933 Auxiliary cycle for tool or workpiece measuring cycles
This cycle must be available in either the part program memory or in the UMS, because it is
used by all measuring cycles.
3.1.4 L934 Auxiliary cycle for tool or workpiece measuring cycles
This cycle must be available in either the part program memory or in the UMS, because it is
used by all measuring cycles.
3.1.5 L935 Measurement result display selection
This function depends on the
machine configuration.
(See machine tool manufacturer's specifications)
If measurement result displays are stored in the UMS, these are displayed automatically at the
end of the measuring cycle.
_______
*) Version 3.0 and higher
3–2 © Siemens AG 1990 All Rights Reserved 6FC5197- AB70
SINUMERIK 840/850/880 (BN)
