10.91 3 Measuring Cycles Auxiliary Programs
3.1.6 L936 Measurement abort
3.1.6 L936 Measurement abort
This function depends on the
machine configuration.
(See machine tool manufacturer's specifications)
This cycle is required for the function ”Measurement abort signal”. This function provides the
possibility of continuing the machining program when a cycle reset alarm occurs.
The measurement abort signal is normally initiated by the operator by pressing a key on the
machine control panel.
3.1.7 L937 Auxiliary cycle for workpiece measuring cycles
This cycle must be available in either the part program memory or in the UMS, because it is
used by all measuring cycles.
3.1.8 L938 Auxiliary cycle for tool or workpiece measuring cycles
This cycle must be available in either the part program memory or in the UMS, because it is
used by all measuring cycles.
3.1.9 L939 Auxiliary cycle for tool measuring cycles
This function depends on the
machine configuration.
(See machine tool manufacturer's specifications)
This cycle processes the PLC interface of the tool management, when MDC 7000 bit 4 or 5 is
set.
3.2 Internal/external measuring cycle auxiliary programs
Part of the ”external” cycles can also be called directly by the user.
3.2.1 L960 Transfer of ZO data blocks (external)
The cycle is used to transfer ZO data from the ZO memory to the MIB or R parameter and
vice versa.
It is supplied with the standard cycles and described in the associated documentation.
©
Siemens AG 1990 All Rights Reserved 6FC5197- AB70 3–3
SINUMERIK 840/850/880 (BN)
