2 Defining Parameters 08.96
2.7.4 L976 Calibrating the workpiece probe (M)
2.7.4 L976 Calibrating the workpiece probe (M)
R23 = 54321
0 With reference data in the plane (not in the case of
probes with ZD numbers)
1 With reference data in the applicate
2 With arbitrary data in the plane
3 With arbitrary data in the applicate
0 Bore
2 Surface
3 SLOT
0 No calculation of probe ball
1 Calculation of probe ball
0 4 axis directions with NC type 2
1 1 axis direction; state measuring axis and axis direction
2 2 axis directions; state measuring axis
0 No position determination
1 Position determination
not in the case of 1-point measurement
2.7.5 L977/L979 Workpiece measurement (M)
R23 = 1 Measure hole
2 Measure shaft
11 Measure slot
12 Measure web
21 ZO determination in the hole
22 ZO determination at the shaft
31 ZO determination in the slot
32 ZO determination at a web
2.7.6 L978 Workpiece measurement (M)
R23 = 0 1-point measurement (ZO determination at a surface)
1 1-point measurement
2 Multi-point measurement paraxial
3 Angle measurement
10 ZO determination at a surface with differential measurement
*)
11 Measure surface with differential measurement
*)
12 Multi-point measurement paraxial with differential measurement
*)
13 Angle measurement with differential measurement
*)
2.7.7 L981 Workpiece measurement (T, M)
R23= 1 Searching for a hole/slot on the end face
2 Searching for a hole/slot at the cylinder
_______
*) Function implemented with Version 3.2 and higher
2–8 © Siemens AG 1990 All Rights Reserved 6FC5197- AB70
SINUMERIK 840/850/880 (BN)
