Siemens SINUMERIK 840C User Manual

01.93 7 Measuring in JOG Mode (SINUMERIK 880/880 GA2)
7.1.1 Operating and function sequence
Explanation of the input values:
TO area
Number of the TO area in which the determined tool data for the tool being measured are to
be stored.
The TO area is preselected via the channel and is displayed here.
The number of TO areas depends on the machine
configuration.
(See information supplied by the machine tool
manufacturer).
Tool offset
Tool offset number D... The determined tool data are stored under this tool number.
Tool type (1-39)
Tool type of the tool to be measured.
1 - 9 : Calculation of the tool geometry via the set plane
10 - 39 : Additional information radius/L1/L2 required! See description below (measurement
parameters).
Tool probe
Number of tool probe.
The number of tool probes depends on the machine
configuration.
(See information supplied by the machine tool
manufacturer).
Empirical value memory no.
The number of the empirical value memory to be used must be entered here.
If the value "0" is entered the tool length required is calculated without using an empirical
value.
©
Siemens AG 1990 All Rights Reserved 6FC5197- AB70 7–3
SINUMERIK 840/850/880 (BN)
