Siemens SINUMERIK 840C User Manual

01.93 10 Lists
10.3 Result parameter
Result parameters:
P No. Calibration Measurement
R200
Trigger point Actual value
minus direction Abscissa
L1 (1st cutting edge) Actual value
R201 Trigger point Difference
minus direction Abscissa
L1 (1st cutting edge) Difference
R202 Trigger point Actual value
plus direction Abscissa
L1 (1st cutting edge) Actual value
R203 Trigger point Actual value
plus direction Abscissa
L1 (1st cutting edge) Difference
R204 Trigger point Actual value
minus direction Ordinate
D/R (1st cutting edge) Actual value
R205 Trigger point Difference
minus direction Ordinate
D/R (1st cutting edge) Difference
R206 Trigger point Actual value
plus direction Ordinate
L1 (2nd cutting edge) Actual value
R207 Trigger point Difference
plus direction Ordinate
L1 (2nd cutting edge) Difference
R208 Trigger point Actual value
minus direction Applicate
L2 (2nd cutting edge) Actual value
R209 Trigger point Actual value
minus direction Applicate
L2 (2nd cutting edge) Difference
R210 Trigger point Actual value
plus direction Applicate
D/R (2nd cutting edge) Actual value
R211 Trigger point Difference
plus direction Applicate
D/R (2nd cutting edge) Difference
R212
D memory No.
R213
EV memory No.
R214
Empirical value
R215
R216
Tool type
R217
Werkzeugtyp
R218
R219
L982
Tool measurement
MDC area probe data
Cycle number
Probe number
Alarm number
© Siemens AG 1990 All Rights Reserved 6FC5197- AB70 10–31
SINUMERIK 840/850/880 (BN)
