10.91 1 Introduction
1.9.2 Logging via CP315 with the SINUMERIK 840/880
– Definition of time of day
Code: (@Z
*
ZZ
*
SS
*
)LF
Format: Default= 14:30:21 (8 digits)
*
= 2:30:21 pm (11 digits)
Column No.
Line No./assignment to basic or supplementary line
0 = base line
1 = supplementary line
.
.
8 = supplementary line
Identifier for time of day
Option
– Definition of date
Code: (@D
*
ZZ
*
SS
*
)LF
Format: Default= day.month.year (8 digits)
1= month/day/year pm (8 digits)
Column No.
Line No.
Identifier for date
Option
• Part 3
Part 3 consists of the description of the first and last line of the table frame.
Code: (@A
*
ZZ
*
SS @----@ )LF
Specification of the first and last line as a fixed text
Column No.
Line No. of first line
Identifier for first and last line
• Part 4
In Part 4, a description is given of the measuring points, the table frame and the variables
of the basic and supplementary lines. Part 4 consists of:
– Specification of locations of decimal points of the measuring points
Code: (@M
*
ZZ
*
SS )LF
Column No. (location of decimal point of measuring point No.)
Line No. (location of decimal point of measuring point No.)
Beginning of entry of measurement results in the table
Identifier for measuring point
©
