3.3 Mounting the TCU on the operator panel front without mounting
bracket
The OP 010S operator panel front and the TCU can be screwed together without any additional
mounting brackets.
① 4 x M3 screws to fasten the TCU support plate to the OP 010S
② TCU support plate
③ 10 mm clearance
Figure 3-2 Mounted TCU with OP 010S, front, side and rear view
Mounting
3.3 Mounting the TCU on the operator panel front without mounting bracket
TCU 30.3
Manual, 09/2017, A5E40874197 23
