Spare parts / accessories
8
8.1 Accessories
Table 8-1 Accessories for the TCU
Component Description Quantity Article number
Mounting bracket Mounting bracket for PCU, video link re‐
ceiver or TCU behind operator panel front
1 set
(2 items)
6FC5248-0AF20-2AA0
Direct key cable Ribbon cable for connection of the direct
key interfaces for OP and TCU.
1 6FC5347-0AF10-0AA0
Industrial
Ethernet ca‐
ble
IE FC Standard Ca‐
ble GP 2 x 2 (Type A)
4-core, shielded TP installation cable for
connection to IE FC Outlet RJ45/
IE FC RJ45 Plug; PROFINET-compatible;
with UL approval;
sold by the meter (max. 1000 m; min. 20 m);
1 6XV1840-2AH10
IE FC Trailing Cable
GP 2 x 2 (Type C)
4-core, shielded TP installation cable for
connection to IE FC Outlet RJ45/
IE FC RJ45 Plug 180/90 for use in trailing
cables; PROFINET-compatible; without UL
approval;
sold by the meter (max. 1000 m; min. 20 m);
1 6XV1840-3AH10
Plug con‐
nector
IE FC RJ45 Plug 180 RJ plug connector for Industrial Ethernet
with robust metal housing and integrated
cutting/clamping contacts; with 180° outgo‐
ing cable
1 6GK1901-1BB10-2AA0
Spare parts for the TCU
There are no parts of this device that can be replaced by the user.
8.2 Handling membrane connectors
When replacing parts it can sometimes be necessary to disconnect membrane connectors
from the boards and reconnect them again.
This should be done as follows:
TCU 30.3
Manual, 09/2017, A5E40874197 83
