Symbol Meaning
RESET alarm
Cancel alarm
HMI alarm
Dialog alarms of the HMI
PLC alarm
PLC alarm of the SQ type (alarm number from 800000)
Safety alarms
Machine manufacturer
Please refer to the machine manufacturer's instructions.
Alarm, error, and system messages
15.1 Displaying alarms
