10.6 Further cycles and functions
10.6.1 Swivel plane/tool (CYCLE800)
The CYCLE800 swivel cycle is used to swivel to any surface in order to either machine or
measure it. In this cycle, the active workpiece zeros and the work offsets are converted to the
inclined surface taking into account the kinematic chain of the machine by calling the
appropriate NC functions - and rotary axes (optionally) are positioned.
Swiveling can be realized:
axis by axis
via solid angle
via projection angle
directly
Before the rotary axes are positioned, the linear axes can be retracted if desired.
Swiveling always means three geometry axes.
In the basic version, the following functions
3 + 2 axes, inclined machining and
toolholder with orientation capability
are available.
Setting/aligning tools for a G code program
The swivel function also includes the "Setting tool" and "Aligning milling tool" functions.
Contrary to swiveling, when setting and aligning, the coordinate system (WCS) is not rotated
at the same time.
Prerequisites before calling the swivel cycle
A tool (tool cutting edge D > 0) and the work offset (WO), with which the workpiece was
scratched or measured, must be programmed before the swivel cycle is first called in the main
program.
Example:
N1 T1D1
N2 M6
N3 G17 G54
N4 CYCLE800(1,"",0,57,0,0,0,0,0,0,0,0,0,1,0,1)) ;swivel ZERO to
;initial position of the
;machine kinematics
N5 WORKPIECE(,,,,"BOX",0,0,50,0,0,0,100,100) ;blank agreement for
;simulation and
;recording
Programming technological functions (cycles)
10.6 Further cycles and functions
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 631
