9 Alarms 01.93
9.3 Alarm description
4007
Wrong MC programs loaded
Explanation:
Remedy:
Wrong auxiliary cycles (L93x, L96x)
Load auxiliary cycles from measuring cycle diskette (Version 20)
4008
Check MDC (Nxxxx)
Explanation:
Remedy:
Block number = MDC number (as alarm 4200)
Correct MDC
4009
Measurement not possible
Explanation:
Remedy:
Coordinate rotation or scale factor is selected
Deselect coordinate rotation or scale factor before measuring cycle
4010
Probe is defective
Explanation: The probe carries 1 signal already before the measurement path ”2a” is
started.
•
Setpoint position has been specified incorrectly (probe deflected)
•
Probe fault, transmits 1 signal continuously.
4011
Probe does not switch
Reason: Probe ”2a” has been completely traversed five times without a
measuring signal having been transmitted.
•
Set position has been incorrectly specified.
•
Probe does not transmit a signal despite being deflected.
4012
Probe collision
Reason: A switching signal has been transmitted as a result of intermediate
positioning operations.
•
Possibly collision
•
Set position has been incorrectly specified.
9–8 © Siemens AG 1990 All Rights Reserved 6FC5197- AB70
SINUMERIK 840/850/880 (BN)
