1 Introduction 10.91
1.9.2 Logging via CP315 with the SINUMERIK 840/880
– Specification of location of tolerance violation
Code: (@O
*
SS
*
X )LF
ASCII representation of tolerance violation identifier.
Presetting: ”
*
”
Column No.
Identifier for tolerance violation
Option
– Definition of perpendicular lines of the table frame
The table frame must be input including blanks
Code: (@R
*
ZZ
*
SS | | | | )LF
Table frame as a fixed text
Column No.
Line No.
Identifier for table frame
– Description of table variables
Column No.
Assignment to basic or supplementary line
0 = Basic line
1 = 1st supplementary line
.
.
8 = 8th supplementary line
Identifier for description of table variables
Code: (@T
*
Z
*
SS @Rxxx
*
Fyy.z
)LF
max. 3 digits
Output format
yy = Total number of decimal places
z = Number of places after the decimal point
No. of R parameters to be logged, e.g. R 219
– Definition of time of day
Code: see above
The variables of the basic line and all possible supplementary lines must be defined one.
First define all variables of the basic line, then those of the first supplementary line etc.
• Part 5
Part 5 consists of the end identifier for form description.
Code: (@E)LF
End identifier
1–32 ©
Siemens AG 1990 All Rights Reserved 6FC5197- AB70
