1.9.2 Logging via CP315 with the SINUMERIK 840/880
• Initiation for transmission for header data
(external call of L988)
.
.
R39=xxxxx1xx
R40=------------
.
.
R45=------------
L988
.
.
Transfer R39
Channel No.
transferred
Initiate
transmission
MPF <Workp. progr.>
L988
R39
Channel No.=<No.>
Coordination
bit
NC PLC
• Transmission of control parameter R39
(External call of L988)
.
.
R39=xxxxx3xx
L988
.
.
Transfer R39
Set coordination
bit
MPF <Workp. progr.>
L988
R39
Coordination
bit
NC PLC
