10.91 1 Introduction
1.9.2 Logging via CP315 with the SINUMERIK 840/880
• Suggestion for a solution
Prerequisites: configuration of the computer link via CP315, configuration of the FB
package subfunctions ”Logging of measurement results” and ”PLC controlled data output”
and activation of the logging function via MDC.
The following procedure is then suggested:
– Preparation of a part program for configuring the form. The part program is as
follows:
%MPF 200
( @C*80 )
( @L*72 )
( @F*1*1 @--------@ @-------------@ @-------------@ @-------------@
@------------@ @-------------@ @--------@ )
( @F*2*1 @I@ )
( @F*2*80 @I@ )
( @F*3*1 @I part number.......:@ )
( @F*3*52 @Datum:@ )
( @F*3*71 @Seite:@ )
( @F*3*80 @I@ )
( @F*4*1 @I@ )
( @F*4*80 @I@ )
( @F*5*1 @I order number....:@ )
( @F*5*80 @I@ )
( @F*6*1 @I@ )
( @F*6*80 @I@ )
( @F*7*1 @I program number....:@ )
( @F*7*45 @ serial number......:@ )
( @F*7*80 @I@ )
( @F*8*1 @------@ @-------------@ @-------------@ @-------------@
@-------------@ @-------------@ @---------@
( @F*9*1 @I@ )
( @F*9*80 @I@ )
( @F*10*1 @I measuring@ @points@ )
( @F*10*15 @setpoint@ @ actual@ @value toleran@ @ce limit set@
@ point Tim@ @e of day@ )
( @F*10*80 @I@ )
( @F*11*1 @I@ )
( @F*11*42 @+@ )
( @F*11*51 @- @ @ difference@ )
( @F*11*80 @I@ )
( @F*12*1 @------@ @-------------@ @-------------@ @-------------@
@-------------@ @-------------@ @---------@ )
( @V*3*23 @R40*F8.0 )
( @V*5*23 @R41*F8.0 )
( @V*7*23 @R43*F8.0 )
( @V*7*65 @R44*F8.0 )
( @D*3*58 )
( @S*3*77 )
Part 1
Part 2
© Siemens AG 1990 All Rights Reserved 6FC5197- AB70 1–41
SINUMERIK 840/850/880 (BN)
