3.2.7 Operating with gestures
Finger gestures to operate the touch display
Tap
● Select window
● Select an object
● Activate entry field
Tapping and holding
● Open object to be changed
Vertical swipe with 1 finger (flick)
● Scrolling in lists
● Scrolling in files
Vertical swipe with 2 fingers (flick)
● Laterally scrolling in lists
● Laterally scrolling in files
Vertical swipe with 3 fingers (flick)
● Scrolling to the beginning or end of lists
● Scrolling to the beginning or end of files
Note:
The distance between the fingers must be at least
10 mm so that the 3 fingers are reliably identified.
Horizontal swipe with 1 finger (flick)
● Scrolling in lists with lots of columns
System characteristics
3.2 Operator controls and display elements
PPU 1740
Equipment Manual, 01/2019, A5E47615272B AA 35
