Configuring Quick Reference
Configuring switch list
9 Press button (13) once (selection level).
10 Press button (13) once (process control level).
Controller is now in manual mode.
+
NOTE
[ ] reflects the factory setting.
Config.
switch
Setting Function
S1 Controller type
[0]
1
2
3
4
5
6
7
Fixed setpoint / three-component controller/controller with 2 internal set-
points
Fixed setpoint / three-component controller with 5 internal setpoints
Slave/synchro/SPC controller with internal/external switchover
Ratio controller
Control station / process variable indicator
Program controller (not for types 6DR1901-, 6DR1904-)
Fixed setpoint controller with one setpoint
1)
Slave controller without int/ext switchover
1)
1)
as of software version 3
S2 Output structure
[0]
1
2
3
K-output
S-output: Two-step controller with 2 outputs heating/cooling
S-output: Three-step controller for motorized drives, internal
feedback
S-output: Three-step controller for motorized drives,
external feedback
S3 Mains frequency suppression
[0]
1
50 Hz
60 Hz
S4 Standard input AI1 (I, mV, R, P, T) - Transmitter fault signal
[0]
1
2
3
UNI-input AI1 min on sensor breakage without MUF
UNI-input AI1 min on sensor breakage with MUF
UNI-input AI1 max on sensor breakage without MUF
UNI-input AI1 max on sensor breakage with MUF
S5 Input signal AI1
[0]
1
2
mV (linear), with range plug I [mA] or U [V]
Thermocouple with internal reference junction
Thermocouple with external reference junction
Exit to pro-
cess control
level
BASIC SETTINGS
ANALOG INPUTS
