Siemens SIPART DR19 User Manual

SIPART DR19
C73000-B7474-C140-06
61
Quick Reference Configuring
3
4
5
Pt100 4-wire connection
Pt100 3-wire connection
Pt100 2-wire connection
6
7
Resistance transmitter with R < 600 Ω
Resistance transmitter with R < 2,8 kΩ
S6 Thermocouple type AI1 (only effective when S5 = 1/2)
[0]
1
2
3
4
5
6
7
8
9
10
Type L
Type J
Type K
Type S
Type B
Type R
Type E
Type N
Type T
Type U
Any type (without linearization)
S7 Temperature unit AI1 and AI3 with UNI module (only effective when
S5 or S10 = 1/2/3/4/5)
[0]
1
2
Degrees Celsius
Degrees Fahrenheit
Degress Kelvin
S8 Input signal AI2 (slot 2) and transmitter fault signal
[0]
1
2
3
I [0 ... 20 mA] or U, R, P, T without MUF
I [0 ... 20 mA] or U, R, P, T with MUF
I [4 ... 20 mA] or U without MUF
I [4 ... 20 mA] or U with MUF
S9 Input signal AI3 (slot 1) and transmitter fault signal
[0]
1
2
3
4
5
6
7
I [0 ... 20 mA] or U, R, P, T without MUF
I [0 ... 20 mA] or U, R, P, T with MUF
I [4 ... 20 mA] or U without MUF
I [4 ... 20 mA] or U with MUF
UNI-module min. on sensor breakage without MUF
UNI-module max. on sensor breakage without MUF
UNI-module min. on sensor breakage with MUF
UNI-module max. on sensor breakage with MUF
Config.
switch
Setting Function
ANALOG INPUTS

Siemens SIPART DR19 Specifications

General

Brand	Siemens
Model	SIPART DR19
Category	Controller
Language	English
