Configuring Quick Reference
Logic of DO on allocated control signals
24 V = High 0 V = High
S76
S77
S78
S79
S80
S81
S82
RB
[0] 1
RC
[0] 1
H[0]1
Nw [0] 1
A1/A2 [0] 1
A3/A4 [0] 1
MUF [0] 1
Allocation of A1/A2 and A3/A4 to process variables
xdx1x wxvwvyy1y2AIAIAIAIAI AI |xd|
*)
1 2 3 1A 2A 3A
S83
S84
A1/A2[0]1234567 8 910111213 14 15
A3/A4[0]1234567 8 910111213 14 15
*) as of software version -B9
S85 Function of limit monitor A1/A2
[0]
1
2
A1 max / A2 min
A1 min / A2 min
A1 max / A2 max
S86 Function of limit monitor A3/A4
[0]
1
2
A3 max / A4 min
A3 min / A4 min
A3 max / A4 max
S87 Display and setting of limit values A1 to A4 in the process control
level
Indicator Parameter Signalling of violated limit
SP-W (2)
1)
adustable values via L1 to L4
1)
[0]
1
2
3
4
5
6
no no A1/A2/A3/A4
no no A3/A4 (for S1= 05)
no no no (for S1=1 or 5)
A3/A4 no A3/A4 (for S1=5)
A1/A2/A3/A4 no A1/A2/A3/A4
A3/A yes A3/A4 (for S1=5)
A1/A2/A3/A4 yes A1/A2/A3/A4
Note:
In switch positions 1,2,3 and 5 the lamps L1 and L2 are free for signalling
of program 1 or 2 running (with S1 = 5).
1)
In this case the parameter names are indicated with the frequency 0.5 by the
lamps L1 to L4. By pointed and addressed limit value the defined signal LED flash-
es with the frequency 0.9.
Config.
switch
Setting Function
DIGITAL INPUT
LIMIT MONITORS
