SIPART DR19
78 C73000-B7474-C140-06
Configuring Quick Reference
Parameters when S10=6/7 (resistance based sensor)
1)
The decimal point in the measuring range must be oberved!
Definition of parameters when S10 = 6/7 (resistance based sensor)
Parameter/Function Param.
names
Min Max Factory
setting
Eng. unit
Decimal point
Start of scale value
Full scale value
MP3
MA3
ME3
_.----
-1999
-1999
----
9999
9999
.-
0,0
100,0
-
Calibrated value for MA3
Calibrated value for ME3
CA3
1)
CE3
1)
present output value
present output value
%
MP3 MP3 defines the position of the decimal point for the measuring range.
MA3/
ME3
CA3/
CE3
Definition of measuring range
Method 1: resistance values are known
Select MA3 and ME3 parameters and enter known resistance values: CA3 and CE3
parameters are ignored.
Method 2: resistance values unknown
Calibrate start of scale
value
• Set control element to 0% and select CA3 parameter;
• Press button (9) until 0.0 is displayed;
Calibrate full scale value
• Set control element to 100% and select CE3 parameter;
• Press button (9) until 100.0 is displayed;
Line resistance is then trimmend automatically; parameters MA3/ME3 are ignored.
---
