Assembly and Installation Information
SIPART DR22/DR24
C79000-M7474-C38-01
18
5.4 Insertion of Modules
The modules are inserted from the rear side of the device and locked.
Important:
- See Figure 2 for the slots.
- The slots are coded.
- The slot layout and the allocation of the inputs and outputs are assigned by
programming.
Possible slot layout:
Slot
Action Module
1 -- -- -- -- main circuit board
2 AE4 6DR2800-8J U/I module or
6DR2800-8R R module or
6DR2800-8V UNI module (TC/RTD/R/mV) or
(6DR2800-8P Pt100 module or
6DR2800-8T TC module) *)
3 AE5 6DR2800-8J U/I module or
6DR2800-8R R module or
6DR2800-8V UNI module (TC/RTD/R/mV) or
(6DR2800-8P Pt100 module or
6DR2800-8T TC module *)
4 SES 6DR2803-8P Profibus DP module or
6DR2803-8C RS232/RS485 module
5 AE9 to AE11 6DR2800-8A 3 x U/I module or
AA7 to AA9
BE5 to BE7
6DR2802-8B 3 x AA/ 3 x BE module or
AA7 and St 6DR2802-8A y-hold module or
BE5 to BE9 6DR2801-8C 5 BE module or
BA9 to BA12 and
BE5 to BE6
6DR2801-8E 4 BA/2BE module or
BA9 to BA10 6DR2801-8D 2 BA relay module
6 AE6 to AE8 6DR2800-8A 3 x U/I module or
AA4 to A6
BE10 to BE12
6DR2802-8B 3 x AA/3 x BE module or
AA4 and St 6DR2802-8A y-hold module or
BE10 to BE14 6DR2801-8C 5 BE module or
BA13 to BA16 and
BE10 to BE11
6DR2801-8E 4 BA/2BE module or
BA13 to BA14 6DR2801-8D 2 BA relay module
*) W e recommend the installation of the UNI module 6DR2800-8V.
