13SIPROTEC 4/5, Injection Unit 7XT71, Product Information
C53000-B1174-C128-7, Edition 09.2016
Injection Unit 7XT7100-0EA00 for Panel Flush Mounting or Cubicle Installation
Fig. 7-2 Injection Unit 7XT7100-0EA00, Housing for Panel Flush Mounting or
Cubicle Installation
Front view
Panel cutout
∅ 5 / 0.2
or M 4
∅ 6 / 0.24
71
+2
/
2.8
+0.08
245
+1
/ 9.65
+0.04
Dimensions in mm / inch
Side view
Mounting
plate
56.5 ± 0.3 /
2.22 ± 0.01
255.8 ± 0.3 / 10.07 ± 0.01
7.3 /
0.29
5.4 / 0.21
75 / 2.95
70 / 2.76
266 / 10.47
244 / 9.61
172 / 6.7729.5 / 1.16
34 /
1.34
