5SIPROTEC 4/5, Vorschaltgerät 7XT71, Produktinformation
C53000-B1174-C128-7, Ausgabestand 09.2016
3 Verwendete Symbole
Tabelle 3-1 Verwendete Symbole
Nr. Symbol Beschreibung
1 Gleichstrom
IEC 60417-5031
2 Wechselstrom
IEC 60417-5032
3 Gleich- und Wechselstrom
IEC 60417-5033
4 Drehstrom
5Erde
IEC 60417-5017
6 Schutzleiter
IEC 60417-5019
7 Vorsicht, Risiko eines
elektrischen Schlages
8 Vorsicht, Risiko einer Gefahr
ISO 7000-0434
