28 SIPROTEC 7SJ81/7SK81 V4.7, Produktinformation
E50417-K1150-C462-A2, Ausgabestand 02.2012
Front-USB-Schnittstelle
Die USB-Schnittstelle für die Verbindung zwischen dem Schutzgerät und
dem PC.
Bild 9 USB-Schnittstelle
Belegung der USB Buchse
Pin-Nr. 1 2 3 4 Gehäuse
USB VBUS
(unbenutzt)
D- D+ GND Schirm
