Siemens SIPROTEC 7UT635*-* N series User Manual

A.1 Ordering Information and Accessories
497
7UT613/63x Manual
C53000-G1176-C160-2
1)
Not possible with surface mounting housing (position 9 = B). For the surface mounted version, please order a device
with the appropriate electrical RS485 interface and accessories in accordance with A.1 under „External Converters“
1)
Not possible with surface mounting housing (position 9 = B). For the surface mounted version, please order a device
with the appropriate electrical RS485 interface and accessories in accordance with A.1 under „External Converters“
2)
Cannot be delivered in connection with 9th digit = B.
1)
In case of a connection to a RTD box 7XV5662-xAD10, a RS485-LWL converter 7XV5650-0xA00 is required.
System Interfaces (rear side, port B) Pos. 11
No system interface 0
IEC 60870-5-103 protocol, electrical RS232 1
IEC 60870-5-103 protocol, electrical RS485 2
IEC 60870-5-103 protocol, optical 820 nm, ST connector 3
Profibus FMS Slave, electrical RS485 4
Profibus FMS slave, optical, single ring, ST connector
1)
5
Profibus FMS slave, optical, double ring, ST connector
1)
6
For more interface options see Additional Specification L 9
Additional Specification L for Further System Interfaces (device rear port B)
(only if Pos. 11 = 9)
Pos. 21 Pos. 22
PROFIBUS DP Slave, RS485 0 A
Profibus DP Slave, optical 820 nm, double ring, ST connector
1)
0B
Modbus, RS485 0D
Modbus, 820 nm, optical, ST connector
2)
0E
DNP3.0, RS485 0G
DNP3.0, optical, 820 nm, ST connector
2)
0H
IEC 61850, 100 Mbit Ethernet, double electrical, RJ 45-connector 0 R
IEC 61850, 100 Mbit Ethernet, optical, ST-connector
2)
0S
Function Interface (rear side, port C) Pos. 12
DIGSI / Modem / Browser, electrical RS232 1
DIGSI / Modem / Browser / RTD-box, electrical RS485 2
For further interface options see Additional Specification M 9
Additional Specification M for Further Function Interfaces
(device rear port C and D) (only if pos. 12 = 9)
Pos. 23 Pos. 24
Port C: DIGSI / Modem / Browser, electrical RS232 1
Port C: DIGSI / Modem / Browser / RTD-box, electrical RS485 2
Port D: RTD-box, 820 nm, optical, ST connector
1)
A
Port D: RTD-Box, electrical RS485 F

Siemens SIPROTEC 7UT635*-* N series Specifications

General

Brand	Siemens
Model	SIPROTEC 7UT635*-* N series
Category	Protection Device
Language	English
