A.9 Information List
605
7UT613/63x Manual
C53000-G1176-C160-2
5725 Diff. prot: Adaption factor CT I5
(Diff CT-I5:)
Diff. Prot VI ON
OFF
5726 Diff. prot: Adaption factor CT I6
(Diff CT-I6:)
Diff. Prot VI ON
OFF
5727 Diff. prot: Adaption factor CT I7
(Diff CT-I7:)
Diff. Prot VI ON
OFF
5728 Diff. prot: Adaption factor CT I8
(Diff CT-I8:)
Diff. Prot VI ON
OFF
5729 Diff. prot: Adaption factor CT I9
(Diff CT-I9:)
Diff. Prot VI ON
OFF
5730 Diff. prot: Adaption factor CT I10
(DiffCT-I10:)
Diff. Prot VI ON
OFF
5731 Diff. prot: Adaption factor CT I11
(DiffCT-I11:)
Diff. Prot VI ON
OFF
5732 Diff. prot: Adaption factor CT I12
(DiffCT-I12:)
Diff. Prot VI ON
OFF
5733 Diff. prot: Adaption factor CT M1
(Diff CT-M1:)
Diff. Prot VI ON
OFF
5734 Diff. prot: Adaption factor CT M2
(Diff CT-M2:)
Diff. Prot VI ON
OFF
5735 Diff. prot: Adaption factor CT M3
(Diff CT-M3:)
Diff. Prot VI ON
OFF
5736 Diff. prot: Adaption factor CT M4
(Diff CT-M4:)
Diff. Prot VI ON
OFF
5737 Diff. prot: Adaption factor CT M5
(Diff CT-M5:)
Diff. Prot VI ON
OFF
5738 Diff. prot: Adaption factor aux. CT
IX1 (Diff CT-IX1:)
Diff. Prot VI ON
OFF
5739 Diff. prot: Adaption factor aux. CT
IX2 (Diff CT-IX2:)
Diff. Prot VI ON
OFF
5740 Diff. prot: Adaption factor aux. CT
IX3 (Diff CT-IX3:)
Diff. Prot VI ON
OFF
5741 Diff. prot: Adaption factor aux. CT
IX4 (Diff CT-IX4:)
Diff. Prot VI ON
OFF
5742 Diff: DC L1 (Diff DC L1) Diff. Prot OUT * ON
OFF
* LED BO
5743 Diff: DC L2 (Diff DC L2) Diff. Prot OUT * ON
OFF
* LED BO
5744 Diff: DC L3 (Diff DC L3) Diff. Prot OUT * ON
OFF
* LED BO
5745 Diff: Increase of char. phase (DC)
(Diff DC InCha)
Diff. Prot OUT * ON
OFF
* LED BO
6851 >BLOCK Trip circuit supervision
(>BLOCK TripC)
TripCirc.Superv SP * * * LED BI BO
6852 >Trip circuit supervision: trip relay
(>TripC trip rel)
TripCirc.Superv SP ON
OFF
* * LED BI BO 170 51 1 Yes
6853 >Trip circuit supervision: breaker
relay (>TripC brk rel.)
TripCirc.Superv SP ON
OFF
* * LED BI BO 170 52 1 Yes
6861 Trip circuit supervision OFF
(TripC OFF)
TripCirc.Superv OUT ON
OFF
* * LED BO 170 53 1 Yes
6862 Trip circuit supervision is
BLOCKED (TripC BLOCKED)
TripCirc.Superv OUT ON
OFF
ON
OFF
* LED BO 153 16 1 Yes
6863 Trip circuit supervision is ACTIVE
(TripC ACTIVE)
TripCirc.Superv OUT ON
OFF
* * LED BO 153 17 1 Yes
6864 Trip Circuit blk. Bin. input is not
set (TripC ProgFail)
TripCirc.Superv OUT ON
OFF
* * LED BO 170 54 1 Yes
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
