Siemens SIPROTEC 7UT635*-* N series User Manual

A Appendix
606
7UT613/63x Manual
C53000-G1176-C160-2
6865 Failure Trip Circuit (FAIL: Trip cir.) TripCirc.Superv OUT ON
OFF
* * LED BO 170 55 1 Yes
11001 >Reset MinMaxValues (>Reset
MinMax)
Min/Max meter SP ON
OFF
**LEDBIBO
12006 >Frequency prot.: Block Stage f<
(>Freq. f< blk)
Frequency Prot. SP ON
OFF
ON
OFF
* LED BI BO 170 239 1 Yes
12007 >Frequency prot.: Block Stage
f<< (>Freq. f<< blk)
Frequency Prot. SP ON
OFF
ON
OFF
* LED BI BO 170 240 1 Yes
12008 >Frequency prot.: Block Stage
f<<< (>Freq. f<<< blk)
Frequency Prot. SP ON
OFF
ON
OFF
* LED BI BO 70 241 1 Yes
12009 >Frequency prot.: Block Stage f>
(>Freq. f> blk)
Frequency Prot. SP ON
OFF
ON
OFF
* LED BI BO 70 242 1 Yes
12032 Frequency prot.: Pick-up Stage f<
(Freq. f< P-up)
Frequency Prot. OUT * ON
OFF
* LED BO 70 243 2 Yes
12033 Frequency prot.: Pick-up Stage
f<< (Freq. f<< P-up)
Frequency Prot. OUT * ON
OFF
* LED BO 70 244 2 Yes
12034 Frequency prot.: Pick-up Stage
f<<< (Freq. f<<< P-up)
Frequency Prot. OUT * ON
OFF
* LED BO 70 245 2 Yes
12035 Frequency prot.: Pick-up Stage f>
(Freq. f> P-up)
Frequency Prot. OUT * ON
OFF
* LED BO 70 246 2 Yes
12036 Frequency prot.: Trip Stage f<
(Freq. f< TRIP)
Frequency Prot. OUT * ON m LED BO 70 247 2 Yes
12037 Frequency prot.: Trip Stage f<<
(Freq. f<< TRIP)
Frequency Prot. OUT * ON m LED BO 70 248 2 Yes
12038 Frequency prot.: Trip Stage f<<<
(Freq. f<<< TRIP)
Frequency Prot. OUT * ON m LED BO 70 249 2 Yes
12039 Frequency prot.: Trip Stage f>
(Freq. f> TRIP)
Frequency Prot. OUT * ON m LED BO 70 250 2 Yes
14101 Fail: RTD (broken wire/shorted)
(Fail: RTD)
RTD-Box OUT ON
OFF
**LEDBO
14111 Fail: RTD 1 (broken wire/shorted)
(Fail: RTD 1)
RTD-Box OUT ON
OFF
**LEDBO
14112 RTD 1 Temperature stage 1
picked up (RTD 1 St.1 p.up)
RTD-Box OUT ON
OFF
**LEDBO
14113 RTD 1 Temperature stage 2
picked up (RTD 1 St.2 p.up)
RTD-Box OUT ON
OFF
**LEDBO
14121 Fail: RTD 2 (broken wire/shorted)
(Fail: RTD 2)
RTD-Box OUT ON
OFF
**LEDBO
14122 RTD 2 Temperature stage 1
picked up (RTD 2 St.1 p.up)
RTD-Box OUT ON
OFF
**LEDBO
14123 RTD 2 Temperature stage 2
picked up (RTD 2 St.2 p.up)
RTD-Box OUT ON
OFF
**LEDBO
14131 Fail: RTD 3 (broken wire/shorted)
(Fail: RTD 3)
RTD-Box OUT ON
OFF
**LEDBO
14132 RTD 3 Temperature stage 1
picked up (RTD 3 St.1 p.up)
RTD-Box OUT ON
OFF
**LEDBO
14133 RTD 3 Temperature stage 2
picked up (RTD 3 St.2 p.up)
RTD-Box OUT ON
OFF
**LEDBO
14141 Fail: RTD 4 (broken wire/shorted)
(Fail: RTD 4)
RTD-Box OUT ON
OFF
**LEDBO
14142 RTD 4 Temperature stage 1
picked up (RTD 4 St.1 p.up)
RTD-Box OUT ON
OFF
**LEDBO
14143 RTD 4 Temperature stage 2
picked up (RTD 4 St.2 p.up)
RTD-Box OUT ON
OFF
**LEDBO
14151 Fail: RTD 5 (broken wire/shorted)
(Fail: RTD 5)
RTD-Box OUT ON
OFF
**LEDBO
No. Description Function
Type of Information
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
